IKO CF16B Metric Stud Type Cam Follower 35 mm CF16 B Track Roller Bearing CF 16 B

IKO CF16B Metric Stud Type Cam Follower 35 mm CF16 B Track Roller Bearing CF 16 B

Products Visitors: 26775

Product Name: IKO CF16B Metric Stud Type Cam Follower 35 mm CF16 B Track Roller Bearing CF 16 B
Material: Gcr15 Chrome steel
Level: PO/P6/P5/P4/P2
Download: IKO CF16B Metric Stud Type Cam Follower 35 mm CF16 B Track Roller Bearing CF 16 B.pdf

Detailed Product Description: IKO CF16B Metric Stud Type Cam Follower 35 mm CF16 B Track Roller Bearing CF 16 B

Cam Follower Bearing CF16B is a bearing having thick outer ring and a stud to which needle type rollers are built into and it is a bearing having small friction coefficient and excellent rotational performance designed for outer ring revolution.With the purpose of increasing the load area effectively,the radial gap of BEARING CF16B is smaller than the general needle roller bearings. Therefore, it alleviates the impact load, and a stable long life is gained. Since the stud undergoes screw processing and stepped processing, they can be attached easily.

IKO BEARING CF16B Cam Follower Bearing CF16B Track Roller Bearing CF16B

Related models and specifications of Bearing CF16B

CF KR SPECIFICATIONS
Model		Weight	d	D	C	B1	B2	G	G1
No Seal	Reference model	(gram)	mm	mm	mm	mm	mm	G	mm
CF 3	KR10	4.5	3	10	7	17	9	M3X0.5	5
CF 4	KR12	7.5	4	12	8	20	11	M4X0.7	6
CF 5	KR13	10.5	5	13	9	23	13	M5X0.8	7.5
CF 6	KR16	18.5	6	16	11	28	16	M6X1	8
CF 8	KR19	28.5	8	19	11	32	20	M8X1.25	10
CF10	KR22	45	10	22	12	36	23	M10X1.25	12
CF10-1	KR26	60	10	26	12	36	23	M10X1.25	12
CF12	KR30	95	12	30	14	40	25	M12X1.5	13
CF12-1	KR32	105	12	32	14	40	25	M12X1.5	13
CF16	KR35	170	16	35	18	52	32.5	M16X1.5	17
CF18	KR40	250	18	40	20	58	36.5	M18X1.5	19
CF20	KR47	460	20	47	24	66	40.5	M20X1.5	21
CF20-1	KR52	385	20	52	29	66	40.5	M20X1.5	21
CF24	KR62	815	24	62	29	80	49.5	M24X1.5	25
CF24-1	KR72	1,140	24	72	29	80	49.5	M24X1.5	25
CF30	KR80	1,870	30	80	35	100	63	M30X1.5	32
CF30-1	KR85	2.03	30	85	35	100	63	M30X1.5	32
CF30-2	KR90	2,220	30	90	35	100	63	M30X1.5	32
