UCP2,NAP2,UKP2+H,SBP2G,SAP2G,UCPX,UCP3,UCPH2,UCPA2,SAPP2,SBPP2
UCF2,UCF3
UCFL2,UCFLX,UCFL3,SALF2G,SBLF2G,SALFTC2G,SBLFTC2G,SBPFL2,SAPFL2
UCFC2,SBPF2,SAPF2,SBPFT2,SAPFL2
UCT2
UCC2,UCFB2,UCFA2,UCHA2
Pillow block bearings quality guarantee
You can replace or refund the products beacause of quality problem within one year after the date you get
them.
Pillow block bearings UCP Series
Shaft Dia | Boundary dimensions(mm) | Bolt Size | Bearing No. | Housing No. | Mass | Bearing Number | ||||||||||
in. | mm | h | a | e | b | s1 | s2 | g | w | Bi | n | Kg | NO | |||
1/2 | 33.3 | 127 | 95 | 38 | 13 | 16 | 15 | 65 | 31 | 12.7 | 3/8 | UC201-8 | P204 | 0.8 | UCP201-8 | |
5/8 | 33.3 | 127 | 95 | 38 | 13 | 16 | 15 | 65 | 31 | 12.7 | 3/8 | UC202-10 | P204 | 0.8 | UCP202-10 | |
20 | 33.3 | 127 | 95 | 38 | 13 | 16 | 15 | 65 | 31 | 12.7 | M10 | UC204 | P204 | 0.8 | UCP204 | |
25 | 36.6 | 140 | 105 | 38 | 13 | 16 | 16 | 70 | 34 | 14.3 | M10 | UC205 | P205 | 1 | UCP205 | |
30 | 42.9 | 165 | 121 | 48 | 17 | 21 | 18 | 83 | 38.1 | 15.9 | M14 | UC206 | P206 | 1.6 | UCP206 | |
35 | 47.6 | 167 | 127 | 48 | 17 | 21 | 19 | 94 | 42.9 | 17.5 | M14 | UC207 | P207 | 2.1 | UCP207 | |
40 | 49.2 | 184 | 137 | 54 | 17 | 25 | 19 | 100 | 49.2 | 19.0 | M14 | UC208 | P208 | 2.6 | UCP208 | |
45 | 54.0 | 190 | 146 | 54 | 17 | 25 | 20 | 108 | 49.2 | 19.0 | M14 | UC209 | P209 | 3 | UCP209 | |
50 | 57.2 | 206 | 159 | 60 | 20 | 25 | 22 | 114 | 51.6 | 19.0 | M16 | UC210 | P210 | 3.6 | UCP210 | |
55 | 63.5 | 219 | 171 | 60 | 20 | 25 | 22 | 126 | 55.6 | 22.2 | M16 | UC211 | P211 | 4.4 | UCP211 | |
60 | 69.8 | 241 | 184 | 70 | 20 | 25 | 25 | 138 | 65.1 | 25.4 | M16 | UC212 | P212 | 6.2 | UCP212 | |
65 | 76.2 | 265 | 203 | 70 | 25 | 29 | 27 | 150 | 65.1 | 25.4 | M20 | UC213 | P213 | 7 | UCP213 | |
70 | 79.4 | 266 | 210 | 72 | 25 | 31 | 27 | 156 | 74.6 | 30.2 | M20 | UC214 | P214 | 7.6 | UCP214 | |
75 | 82.6 | 275 | 217 | 74 | 25 | 31 | 28 | 163 | 77.8 | 33.3 | M20 | UC215 | P215 | 8.5 | UCP215 |
|
|
|
|
|
|
||||||||
|
|
|
|
||||||||
|
|
|
|
