Skf Bearings Distributors Karachi Original sweden Spherical roller thrust bearings 29317 E bearing 85*150*39mm

Skf Bearings Distributors Karachi Original sweden Spherical roller thrust bearings 29317 E bearing 85*150*39mm

Products Visitors: 19740

Product Name: Skf Bearings Distributors Karachi Original sweden Spherical roller thrust bearings 29317 E bearing 85*150*39mm
Material: Gcr15 Chrome steel
Level: PO/P6/P5/P4/P2
Download: Skf Bearings Distributors Karachi Original sweden Spherical roller thrust bearings 29317 E bearing 85*150*39mm.pdf

Detailed Product Description: Skf Bearings Distributors Karachi Original sweden Spherical roller thrust bearings 29317 E bearing 85*150*39mm

About Thrust roller bearings Thrust roller bearings sustain only axial loads, but they are suitable for heavy loads and have high axial rigidity. Spherical thrust roller bearings contain convex rollers and have a self-aligning capability and are free of any influence of mounting error or shaft deflection. Standard cages are machined brass, where the E-type offers a pressed cage for high load capacity.

skf bearings distributors karachi 29317 thrust ball bearings 85*150*39mm

Related models and specifications of skf bearings distributors karachi

Inner dia.	Outer dia.	Tall	Basic dynamic load ratings	Limiting speed
(mm)	(mm)	(mm)	(kN)	Grease	Oil
				(min-1)	(min-1)
29412	60	130	42	283	2600
29413	65	140	45	330	2400
29414	70	150	48	365	2200
29415	75	160	51	415	2100
29416	80	170	54	460	1900
29317	85	150	39	265	2300
29417	85	180	58	490	1800
29318	90	155	39	285	2300
29418	90	190	60	545	1700
29320	100	170	42	345	2100
29420	100	210	67	685	1500
29322	110	190	48	445	1800
29422	110	230	73	845	1400
29324	120	210	54	535	1600
29424	120	250	78	975	1300
29326	130	225	58	615	1500
29426	130	270	85	1080	1200
29328	140	240	60	685	1400
29428	140	280	85	1110	1200
29230	150	215	39	340	1800
29330	150	250	60	675	1400
29430	150	300	90	1280	1100
29232	160	225	39	360	1700
29332	160	270	67	820	1300
29432	160	320	95	1500	1000
29234	170	240	42	425	1600
29334	170	280	67	855	1200
29434	170	340	103	1660	940
29236	180	250	42	450	1600
29336	180	300	73	995	1100
29436	180	360	109	1840	890
29238	190	270	48	530	1400
29338	190	320	78	1150	1100
29438	190	380	115	2010	840
29240	200	280	48	535	1400
29340	200	340	85	1280	980
29440	200	400	122	2230	790
29244	220	300	48	555	1300
29344	220	360	85	1390	940
29444	220	420	122	2300	760
29248	240	340	60	825	1100
29348	240	380	85	1380	910
29448	240	440	122	2400	740
29252	260	360	60	870	1100
29352	260	420	95	1710	810
29452	260	480	132	2740	670
29256	280	380	60	875	1000
29356	280	440	95	1800	790
29456	280	520	145	3350	610
29260	300	420	73	1190	870
29360	300	480	109	2140	700
29460	300	540	145	3450	590
29264	320	440	73	1260	840
29364	320	500	109	2220	680
29464	320	580	155	3700	550
29268	340	460	73	1240	820
29368	340	540	122	2650	610
29468	340	620	170	4400	500
29272	360	500	85	1510	720
29372	360	560	122	2710	590
29472	360	640	170	4500	490
29276	380	520	85	1590	700
29376	380	600	132	3200	550
29476	380	670	175	4900	470
29280	400	540	85	1620	680
29380	400	620	132	3400	530
29480	400	710	185	5450	440
29284	420	580	95	2100	620
29384	420	650	140	3600	500
29484	420	730	185	5500	430
29288	440	600	95	2150	600
29388	440	680	145	3800	480
29488	440	780	206	6400	390
29292	460	620	95	2150	590
29392	460	710	150	4200	460
29492	460	800	206	6600	380
29296	480	650	103	2400	550
29396	480	730	150	4200	450
29496	480	850	224	7500	350
292/500	500	670	103	2540	530
293/500	500	750	150	4300	440
294/500	500	870	224	7850	340
