| Basic Bearing No. | Main Dimension | Load rating / KN | maximum speed | Weight approximate kg | ||||||
| cylindrical bore | tapered bore | d mm | D mm | B mm | r min mm | Dynamic C | Static C0 | Grease r/min | Oil r/min | |
| 126 | 6 | 19 | 6 | 0.3 | 2.53 | 0.475 | 30000 | 36000 | 0.02 | |
| 127 | 7 | 22 | 7 | 0.3 | 2.75 | 0.600 | 26000 | 32000 | 0.04 | |
| 108 | 8 | 22 | 7 | 0.3 | 2.75 | 0.600 | 26000 | 32000 | 0.04 | |
| 129 | 9 | 26 | 8 | 0.6 | 4.15 | 0.895 | 26000 | 30000 | 0.05 | |
| 1200 | 10 | 30 | 9 | 0.6 | 5.55 | 1.19 | 22000 | 28000 | 0.033 | |
| 1201 | 12 | 32 | 10 | 0.6 | 5.70 | 1.27 | 22000 | 26000 | 0.039 | |
| 2301 | 37 | 17 | 1.0 | 12.1 | 2.73 | 17000 | 22000 | 0.082 | ||
| 1202 | 15 | 35 | 11 | 0.6 | 7.60 | 1.75 | 18000 | 22000 | 0.051 | |
| 1203 | 17 | 40 | 12 | 0.6 | 8.00 | 2.01 | 16000 | 20000 | 0.072 | |
| 1204 | 1204K | 20 | 47 | 14 | 1.0 | 10.0 | 2.61 | 14000 | 17000 | 0.120 |
| 1205 | 1205K | 25 | 52 | 15 | 1.0 | 12.2 | 3.30 | 12000 | 14000 | 0.140 |
| 1206 | 1206K | 30 | 62 | 16 | 1.0 | 15.8 | 4.65 | 10000 | 12000 | 0.220 |
| 1207 | 1207K | 35 | 72 | 17 | 1.1 | 15.9 | 5.10 | 8500 | 10000 | 0.320 |
| 1208 | 1208K | 40 | 80 | 18 | 1.1 | 19.3 | 6.50 | 7500 | 9000 | 0.415 |
| 1209 | 1209K | 45 | 85 | 19 | 1.1 | 22.0 | 7.35 | 7100 | 8500 | 0.465 |
| 1210 | 1210K | 50 | 90 | 20 | 1.1 | 22.8 | 8.10 | 6300 | 8000 | 0.525 |
| 1211 | 1211K | 55 | 100 | 21 | 1.5 | 26.9 | 10.0 | 6000 | 7100 | 0.705 |
| 1212 | 1212K | 60 | 110 | 22 | 1.5 | 30.5 | 11.5 | 5300 | 6300 | 0.900 |
| 1213 | 1213K | 65 | 120 | 23 | 1.5 | 31.0 | 12.5 | 4800 | 6000 | 1.150 |
| 1214 | 1214K | 70 | 125 | 24 | 1.5 | 35.0 | 13.8 | 4800 | 5600 | 1.300 |
| 1215 | 1215K | 75 | 130 | 25 | 1.5 | 39.0 | 15.7 | 4300 | 5300 | 1.410 |
| 1216 | 1216K | 80 | 140 | 26 | 2.0 | 40.0 | 17.0 | 4000 | 5000 | 1.730 |
| 1217 | 1217K | 85 | 150 | 28 | 2.0 | 49.5 | 20.8 | 3800 | 4500 | 2.090 |
| 1218 | 1218K | 90 | 160 | 30 | 2.0 | 57.5 | 23.5 | 3600 | 4300 | 2.550 |
| 1219 | 1219K | 95 | 170 | 32 | 2.1 | 64.0 | 27.1 | 3400 | 4000 | 3.210 |
| 1220 | 1220K | 100 | 180 | 34 | 2.1 | 69.5 | 29.7 | 3200 | 3800 | 3.820 |
| 1221 | 1221K | 105 | 190 | 36 | 2.1 | 75.0 | 32.5 | 3000 | 3600 | 4.520 |
| 1222 | 1222K | 110 | 200 | 38 | 2.1 | 87.0 | 38.5 | 2800 | 3400 | 5.330 |
|
|
|
|
||||||||
|
|
|
|
||||||||
|
|
|
|
