Sepecification
| Angular contact Ball Bearing 7002A | ||||||
| Principal | d | 15mm | ||||
| D | 32mm | |||||
| T | 9mm | |||||
| Basic loading rating | Dynamic Cr | 5.65KN | ||||
| Staic Cor | 3.5KN | |||||
| Speed ratings | grease | --r/min | ||||
| Materials: | Gcr15, Gcr15SiMn | |||||
| Bearing Retainer | Nylon,Steel,Brass | |||||
| Grease | SRL Alvanin,SRI2 Chevron,ordinary grease etc. | |||||
| Seal Type | open,Z,ZZ,RS,2RS,2RZ,LU,LLU | |||||
| Module Series | 7000,7200,7300 ,7400series,BNR19 | |||||
| Service | OEM&ODM | |||||
| Quality Standard | ISO9001:2000 | |||||
| Delivery | Within 7-15days after down payment | |||||
| Payment terms: | A:30% T/T inadvance,70% before shippment | |||||
| B:100% T/T at sight | ||||||
| Transport terms | by sea or by air | |||||
| Package: | Single paper box or according to requirements | |||||
| Performance | 1,The most popular types among rolling bearings, widely used in a variety of industries. 2,Radial load and axial load in both directions can be accommodated. 3,Suitable for operation at high speed, with low noise and low vibration. 4,Sealed bearings employing steel shields or rubber seals are filled with the appropriate volume of grease when manufactured. |
|||||
| Application |
electric motors, construction machinery, transmission shafts, gear shafts and various kinds of professional machinery. |
|||||
Part of the bearing specification :
| Bearing No. | Dimension (mm) | ||
| d | D | B | |
| 725C | 5 | 16 | 5 |
| 725A | 5 | 16 | 5 |
| 706C | 6 | 17 | 6 |
| 706A | 6 | 17 | 6 |
| 726C | 6 | 19 | 6 |
| 726A | 6 | 19 | 6 |
| 707C | 7 | 19 | 6 |
| 707A | 7 | 19 | 6 |
| 708C | 8 | 22 | 7 |
| 708A | 8 | 22 | 7 |
| 728C | 8 | 24 | 8 |
| 728A | 8 | 24 | 8 |
| 7900C | 10 | 22 | 6 |
| 7900A5 | 10 | 22 | 6 |
| 7901C | 12 | 24 | 6 |
| 7901A5 | 12 | 24 | 6 |
| 7902C | 15 | 28 | 7 |
| 7902A5 | 15 | 28 | 7 |
| 7903C | 17 | 90 | 7 |
| 7903A5 | 17 | 90 | 7 |
| 7904C | 20 | 37 | 9 |
| 7904A5 | 20 | 37 | 9 |
| 7905C | 25 | 42 | 9 |
| 7905A5 | 25 | 42 | 9 |
| 7906C | 90 | 47 | 9 |
| 7906A5 | 90 | 47 | 9 |
| 7907C | 35 | 55 | 10 |
| 7907A5 | 35 | 55 | 10 |
| 7908C | 40 | 62 | 12 |
| 7908A5 | 40 | 62 | 12 |
| 7909C | 45 | 68 | 12 |
| 7909A5 | 45 | 68 | 12 |
| 7910C | 50 | 72 | 12 |
| 7910A5 | 50 | 72 | 12 |
| 7911C | 55 | 80 | 13 |
| 7911A5 | 55 | 80 | 13 |
| 7912C | 60 | 85 | 13 |
| 7912A5 | 60 | 85 | 13 |
| 7913C | 65 | 90 | 13 |
| 7913A5 | 65 | 90 | 13 |
| 7914C | 70 | 100 | 16 |
| 7914A5 | 70 | 100 | 16 |
| 7915C | 75 | 105 | 16 |
| 7915A5 | 75 | 105 | 16 |
| 7916C | 80 | 110 | 16 |
| 7916A5 | 80 | 110 | 16 |
| 7917C | 85 | 120 | 18 |
| 7917A5 | 85 | 120 | 18 |
| 7918C | 90 | 125 | 18 |
| 7918A5 | 90 | 125 | 18 |
| 7919C | 95 | 190 | 18 |
| 7919A5 | 95 | 190 | 18 |
| 7920C | 100 | 140 | 20 |
| 7920A5 | 100 | 140 | 20 |
| 7921C | 105 | 145 | 20 |
| 7921A5 | 105 | 145 | 20 |
| 7922C | 110 | 150 | 20 |
| 7922A5 | 110 | 150 | 20 |
| 7924C | 120 | 165 | 22 |
| 7924A5 | 120 | 165 | 22 |
| 7926C | 190 | 180 | 24 |
| 7926A5 | 190 | 180 | 24 |
| 7928C | 140 | 190 | 24 |
| 7928A5 | 140 | 190 | 24 |
| 7990C | 150 | 210 | 28 |
| 7990A5 | 150 | 210 | 28 |
| 7932C | 160 | 220 | 28 |
| 7932A5 | 160 | 220 | 28 |
| 7934C | 170 | 290 | 28 |
| 7934A5 | 170 | 290 | 28 |
| 7936C | 180 | 250 | 33 |
| 7936A5 | 180 | 250 | 33 |
| 7938C | 190 | 260 | 33 |
| 7938A5 | 190 | 260 | 33 |
| 7940C | 200 | 280 | 38 |
| 7940A5 | 200 | 280 | 38 |
| 7944C | 220 | 900 | 38 |
| 7944A5 | 220 | 900 | 38 |
| 7948C | 240 | 320 | 38 |
| 7948A5 | 240 | 320 | 38 |
| 7952C | 260 | 360 | 46 |
| 7952A5 | 260 | 360 | 46 |
| 7956C | 280 | 380 | 46 |
| 7956A5 | 280 | 380 | 46 |
| 7000A5 | 10 | 26 | 8 |
| 7000A | 10 | 26 | 8 |
| 7001A5 | 12 | 28 | 8 |
| 7001A | 12 | 28 | 8 |
| 7002A5 | 15 | 32 | 9 |
| 7002A | 15 | 32 | 9 |
| 7003A5 | 17 | 35 | 10 |
| 7003A | 17 | 35 | 10 |
| 7004A5 | 20 | 42 | 12 |
| 7004A | 20 | 42 | 12 |
| 7005A5 | 25 | 47 | 12 |
| 7005A | 25 | 47 | 12 |
| 7006A5 | 90 | 55 | 13 |
| 7006A | 90 | 55 | 13 |
| 7007A5 | 35 | 62 | 14 |
| 7007A | 35 | 62 | 14 |
