SKF 7308 BECBP Single Row Angular Contact Ball Bearing 40X90X23MM

SKF 7308 BECBP Single Row Angular Contact Ball Bearing 40X90X23MM

Products Visitors: 12950

Product Name: SKF 7308 BECBP Single Row Angular Contact Ball Bearing 40X90X23MM
Material: GCr15 bearing steel
Level: P0 P6 P5 P4
Download: SKF 7308 BECBP Single Row Angular Contact Ball Bearing 40X90X23MM.pdf

Detailed Product Description: SKF 7308 BECBP Single Row Angular Contact Ball Bearing 40X90X23MM

SKF Angular contact ball bearings are able to support radial load and axial load. As single row angular contact ball bearings can only support axial load in single direction, matched bearing mounting is often adopted to them as matched parts of bearings, preload for them is more convenient.

Retainers are made of brass, synthetic resins or others subject to individual bearing features and application conditions.

Angular contact ball bearing include:
1) Single row angular contact ball bearing
2) Matched angular contact ball bearing
3) Double row angular contact ball bearing
4) Four-point contact ball bearing

Angular contact ball bearings features :
1) Load capacities are higher than deep groove ball bearings of same dimensions;
2) Used for bearing radial-axial combined loads or pure thrust loads;
3) Low operating friction and high limiting speed.

Series	Angular-contact ball bearing
Bearing NO.	7308 BECBP
Basic size(mm)	d	40
	D	90
	B	23
Basic load ratings	Cr	52.4
Kn	Cor	35.4
Limiting Speeds	grease	14000
N(1/min)	oil	19000
Payment Term	T/T,Western Union,PayPal
Payment Term	Other payment terms depend on our discussion
Mass	0.65kg

Part of the bearing specification :

designation	Dimensions
designation	d (mm)	D (mm)	B (mm)
7200 BECBP	10	30	9
7201 BECBP	12	32	10
7202 BECBP	15	35	11
7202 BECBP	15	35	11
7203 BECBP	17	40	12
7303 BECBP	17	47	14
7204 BECBP	20	47	14
7304 BECBP	20	52	15
7302 BECBP	15	42	13
7204 BECBP	20	47	14
7304 BECBP	20	52	15
7205 BECBP	25	52	15
7305 BECBP	25	62	17
7206 BECBP	30	62	16
7206 BEGBP	30	62	16
7207 BECBP	35	72	17
7307 BECBP	35	80	21
7208 BECBP	40	80	18
7308 BECBP	40	90	23
7209 BECBP	45	85	19
7309 BECBP	45	100	25
7210 BECBP	20	90	50
7215 BECBP	75	130	25
7315 BECBP	75	160	37
7216 BECBP	80	140	26
7316 BECBP	80	170	39
7217 BECBP	85	150	28
7317 BECBP	85	180	41
7218 BECBP	90	160	30
7318 BECBP	90	190	43
7219 BECBP	95	170	32
7319 BECBP	95	200	45
7220 BECBP	100	180	34
7306 BECBP	30	72	19
7310 BECBP	27	110	50
7211 BECBP	21	100	55
7311 BECBP	55	120	29
7212 BECBP	60	110	22
7312 BECBP	60	130	31
7213 BECBP	65	120	23
7313 BECBP	65	140	33
7214 BECBP	70	125	24
7314 BECBP	70	150	35
7320 BECBP	100	215	47
7221 BECBP	105	190	36
7321 BECBP	105	225	49
7222 BECBP	110	200	38
7322 BECBP	110	50	50
7306 BECBP	30	72	19
