SKF 7204CDP4 super-precision Single Row Angular contact ball bearings 20X47X14MM

SKF 7204CDP4 super-precision Single Row Angular contact ball bearings 20X47X14MM

Products Visitors: 7770

Product Name: SKF 7204CDP4 super-precision Single Row Angular contact ball bearings 20X47X14MM
Material: GCr15 bearing steel
Level: P0 P6 P5 P4
Download: SKF 7204CDP4 super-precision Single Row Angular contact ball bearings 20X47X14MM.pdf

Detailed Product Description: SKF 7204CDP4 super-precision Single Row Angular contact ball bearings 20X47X14MM

d		20	mm
D		47	mm
B		14	mm
d₁		29.1	mm
d₂		29.1	mm
D₁		38.7	mm
r_1,2	min.	1	mm
r_3,4	min.	0.3	mm
a		11.6	mm

Model list

Principal dimensions			Attainable speeds		Designation
Principal dimensions			Grease lubrication	Oil-air lubrication
d	D	B
mm			r/min
12	21	5	85000	130000	71801 CD/HCP4
12	32	10	48000	70000	7201 ACD/P4A
15	32	9	68000	106000	7002 CE/P4AH
15	28	7	56000	85000	71902 CD/P4A
15	28	7	75000	115000	71902 CE/P4A
15	28	7	75000	115000	71902 CE/P4AH
15	32	9	67000	100000	7002 CD/HCP4AH
15	24	5	53000	80000	71802 ACD/P4
15	28	7	60000	90000	71902 ACD/HCP4A
15	24	5	60000	90000	71802 CD/P4
15	24	5	63000	100000	71802 ACD/HCP4
15	24	5	70000	110000	71802 CD/HCP4
15	28	7	83000	127000	71902 ACE/HCP4A
15	32	9	60000	95000	7002 ACD/HCP4A
15	32	9	50000	75000	7002 ACD/P4AH
15	35	11	43000	63000	7202 ACD/P4A
15	32	9	75000	115000	7002 ACE/HCP4AH
15	32	9	68000	106000	7002 CE/P4A
15	32	9	56000	85000	7002 CD/P4A
15	28	7	90000	140000	71902 CE/HCP4A
15	32	9	83000	127000	7002 CE/HCP4A
15	35	11	50000	75000	7202 ACD/HCP4A
15	32	9	63000	95000	7002 ACE/P4AH
15	32	9	75000	115000	7002 ACE/HCP4A
15	32	9	67000	100000	7002 CD/HCP4A
15	28	7	68000	106000	71902 ACE/P4A
15	28	7	50000	75000	71902 ACD/P4A
15	28	7	83000	127000	71902 ACE/HCP4AH
15	32	9	63000	95000	7002 ACE/P4A
15	32	9	50000	75000	7002 ACD/P4A
15	28	7	68000	106000	71902 ACE/P4AH
15	28	7	90000	140000	71902 CE/HCP4AH
15	32	9	83000	127000	7002 CE/HCP4AH
15	35	11	48000	70000	7202 CD/P4A
15	32	9	60000	95000	7002 ACD/HCP4AH
15	35	11	60000	85000	7202 CD/HCP4A
15	28	7	70000	100000	71902 CD/HCP4A
15	32	9	56000	85000	7002 CD/P4AH
17	30	7	75000	115000	71903 ACE/HCP4A
17	26	5	60000	90000	71803 ACD/HCP4
17	35	10	56000	85000	7003 ACD/HCP4AH
17	35	10	45000	70000	7003 ACD/P4AH
17	35	10	68000	103000	7003 ACE/HCP4A
17	35	10	56000	88000	7003 ACE/P4AH
17	35	10	56000	85000	7003 ACD/HCP4A
17	30	7	63000	90000	71903 CD/HCP4A
17	26	5	63000	100000	71803 CD/HCP4
17	35	10	60000	95000	7003 CD/HCP4A
17	30	7	75000	115000	71903 ACE/HCP4AH
17	35	10	56000	88000	7003 ACE/P4A
17	35	10	45000	70000	7003 ACD/P4A
17	26	5	53000	85000	71803 CD/P4
17	40	12	53000	75000	7203 CD/HCP4A
17	35	10	63000	95000	7003 CE/P4AH
17	35	10	60000	95000	7003 CD/HCP4AH
17	35	10	75000	115000	7003 CE/HCP4A
17	40	12	45000	67000	7203 ACD/HCP4A
17	30	7	53000	80000	71903 ACD/HCP4A
17	26	5	48000	75000	71803 ACD/P4
17	30	7	70000	106000	71903 CE/P4AH
17	40	12	43000	63000	7203 CD/P4A
17	35	10	75000	115000	7003 CE/HCP4AH
17	30	7	50000	75000	71903 CD/P4A
17	35	10	50000	75000	7003 CD/P4AH
17	30	7	83000	127000	71903 CE/HCP4A
17	30	7	70000	106000	71903 CE/P4A
17	30	7	83000	127000	71903 CE/HCP4AH
17	30	7	45000	67000	71903 ACD/P4A
17	30	7	63000	95000	71903 ACE/P4A
17	30	7	63000	95000	71903 ACE/P4AH
17	40	12	38000	56000	7203 ACD/P4A
17	35	10	68000	103000	7003 ACE/HCP4AH
17	35	10	50000	75000	7003 CD/P4A
17	35	10	63000	95000	7003 CE/P4A
20	32	7	45000	70000	71804 CD/P4
20	42	12	65000	100000	7004 CE/HCP4AL1
20	42	12	65000	100000	7004 CE/HCP4AH1
20	42	12	58000	88000	7004 ACE/HCP4A
20	37	9	52000	78000	71904 ACE/P4AL
20	37	9	52000	78000	71904 ACE/P4AH
20	37	9	56000	88000	71904 CE/P4AH
20	37	9	56000	88000	71904 CE/P4AL
20	42	12	50000	80000	7004 CD/HCP4AH
20	37	9	60000	95000	71904 ACE/HCP4AL
20	37	9	60000	95000	71904 ACE/HCP4AH
20	42	12	43000	63000	7004 CD/P4A
20	42	12	54000	83000	7004 CE/P4A
20	47	14	32000	48000	7204 ACD/P4A
20	42	12	43000	63000	7004 CD/P4AH
20	37	9	53000	75000	71904 CD/HCP4A
20	47	14	38000	56000	7204 ACD/HCP4A
20	37	9	68000	106000	71904 CE/HCP4A
20	47	14	36000	53000	7204 CD/P4A
20	42	12	48000	75000	7004 ACE/P4AL
20	42	12	45000	70000	7004 ACD/HCP4AH
20	42	12	58000	88000	7004 ACE/HCP4AL1
20	42	12	54000	83000	7004 CE/P4AH1
20	42	12	58000	88000	7004 ACE/HCP4AH1
20	42	12	54000	83000	7004 CE/P4AL1
20	42	12	58000	88000	7004 ACE/HCP4AL
20	37	9	68000	106000	71904 CE/HCP4AL
20	37	9	68000	106000	71904 CE/HCP4AH
20	37	9	60000	95000	71904 ACE/HCP4A
